Details
The Spur provides a sense of connection to the trail as if it were an extension of your own body. Allowing you to be fast and efficient with an anti-gravity feel and laser-pointer precision. It begs you to climb more, go farther, and descend anything you may encounter along the way. You're rewarded with free speed as every pump and pedal stroke propels you forward while our SBG Geometry makes sure you're composed for every root, rock or switchback. Don't judge a book by its cover though, with all these lightweight and uphill oriented character traits the Spur requires no adjustment to descend like you're used to, you might actually go faster.
Specs
Frame | Spur Carbon 120mm (UDH) |
---|---|
Fork | Fox Float 34 Factory Fit 4 (120mm) |
Headset | FSA No.57E |
Rear Shock | Fox Float DPS Factory 3 Position (190x45mm) |
Rims/Wheels | DT Swiss XRC 1501 Spline 30 Carbon |
Hubs | DT Swiss 240 Ratchet EXP |
Spokes | DT Swiss Competition Race |
Tires | Maxxis Rekon 3C EXO (2.4) Maxxis Dissector 3C EXO (2.4) |
Crankset | SRAM XO Eagle DUB T-Type (32t/170mm) |
Chainwheel | SRAM XO Eagle DUB T-Type (32t/170mm) |
Bottom Bracket | SRAM XO Eagle DUB |
Chain | SRAM XO Eagle Transmission |
Front Derailleur | N/A |
Rear Derailleur | SRAM XO AXS Eagle Transmission |
Rear Cogs | SRAM XS 1295 T-Type (10-52t) |
Shifters | SRAM POD Ultimate Bridge MMX |
Handlebars | OneUp Carbon Bar SM/MD(800mm x 20mm) LG/XL(800x35) |
Tape/Grips | ODI Elite Flow |
Stem | ANVL Swage (40mm) |
Brake Levers | SRAM G2 RSC |
Brakes | SRAM G2 RSC |
Pedals | N/A |
Saddle | SDG Bel Air 3 or ANVL Forge Cromo |
Seat Post | OneUp Dropper Post SM(150mm) MD(180mm) LG/XL(210mm) |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Hazy Grey / Small | |||
Hazy Grey / Medium | |||
Hazy Grey / Large | 769165686237 | 01.25.11.4414 | COM35698578E |
Hazy Grey / X-Large | |||
Blackberry / Small | 769165686206 | 01.25.11.4411 | SPU24225833Y |
Blackberry / Medium | 769165686220 | 01.25.11.4413 | SPU25173648Y |
Blackberry / Large | 769165686244 | 01.25.11.4415 | SPU24316817Y |
Blackberry / X-Large |
